Leonard TA-300-LF-RF Eye/Face wash unit ROUGH BRONZE

Leonard TA-300-LF-RF Eye/Face wash unit ROUGH BRONZE
Leonard TA-300-LF-RF Eye/Face wash unit ROUGH BRONZE
Call for Price
Part #TA-300-LF-RF
TA-300-LF-RF

Leonard TA-300-LF-RF Eye/Face wash unit ROUGH BRONZE

Inlet: 1/2" Outlet: 1/2" Rough Bronze Finish,
Specification.
Inlets 1/2"
Outlet 1/2"
Minimum Flow(GPM) 2
Maximum Flow(GPM) 10
Overall Width 7"
Overall Height 7"
Overall Depth 5"

Certifications.
ASSE Certified Lead Free
ASSE 1071
CSA Certified

Options.
Chrome Plated Finish CP
Top Inlets TOP
Inlet Thermometers IT



Eye/Face Wash TA-300 LF

ECO-MIX � DURA-trol� solid bimetal thermostat directly linked to valve porting to control the intake of hot and cold water and compensate for supply temperature and pressure fluctuations. DURA-trol is highly responsive and cannot be damaged by extremes in temperature. Thermostatic Mixing Valve can be set to the correct temperature for the application. Locking type temperature regulator to prevent accidental movement set for 85�F (29�C), Recommended Hot Inlet Temperature 140�F. Mixing valve will close down on failure of cold water supply, Mixing Valve with special internal cold water bypass capable of 4 GPM (15 l/min) @ 30 PSI (2.1 Bar) upon failure of hot water supply. Adjustable high temperature limit stop set for 90�F (32�C), Full 1/2" top or bottom inlets and 1/2" top outlet, Integral wall support, Dial thermometer (range 0 to 140�F, -10 to 60�C), Rough bronze finish. Union angle checkstops on inlets

This product is certified to meet Low Lead requirements of wetted surface area containing less than 0.25% lead by weight

Genuine Leonard Valve Product.

Order minimum must be $125 to ship from the factory.
Must meet requirements to ship from factory. Items that ship from the Leonard factory ship within a week and a half to two weeks from order date except when purchasing a special order item. Special order shipping times vary in delivery times.

**Freight charges will apply for all Complete Valve Systems**
